Product Parameters
Supported protocol
ISO 18000-6C, EPC C1G2 standard
Operating frequency
860-960 MHz, customizable range
Read / write range
0-5000 mm; maximum range depends on tag size
Communication interface
Industrial Ethernet, WiFi (2.4G / 5G), RS485
Communication rate
10/100M bps, 9600 b/s-115200 b/s
Power supply
12V internal battery, 10-30V DC, 46-54V POE
Maximum current
<0.72A @ 12V DC
Dimensions
234 x 190 x 60 mm; top cover size 130 x 130 mm
Battery capacity
11800 mAh; supports 48 hours of continuous work and 96 hours of standby time
Mounting method
Nut (2 x M8) mounting
Housing material
ABS top cover + metal bottom shell
Housing color
Gray top cover, silver-white bottom shell
Indicators
6 LED indicators
Communication ports
8-pin (M12A) + 5-pin (M12A) + 4-pin (M12D)
External antenna
3 x SMA interfaces
Operating temperature
-30 C to +65 C
Operating humidity
5%-95% RH
IP rating
IP65
