Product Parameters
Supported protocol
ISO 18000-6C, EPC C1G2 standard
Operating frequency
860-960 MHz, customizable range
RF output power
1-30 dBm, configurable
Communication interface
Industrial Ethernet, WiFi (2.4G / 5G), RS485
Communication rate
10/100M bps, 9600 b/s-115200 b/s
Power supply
48V POE (46-54V), 24V DC (10-30V)
Maximum current
<0.38A @ 24V DC
Dimensions
135 x 135 x 42 mm; top cover size 130 x 130 mm
Weight
580 g
Mounting method
Nut (4 x M5) mounting or accessory bracket mounting
Housing material
ABS top cover + metal bottom shell
Housing color
Gray top cover, silver-white bottom shell
Indicators
6 LED indicators
Communication ports
8-pin (M12A) + 5-pin (M12A) + 4-pin (M12D)
External antenna
4 x SMA interfaces
Operating temperature
-40 C to +60 C
Operating humidity
5%-95% RH
IP rating
IP67
