Technical Specifications
Product model
RGW6229
Product category
Industrial & High-Temperature RFID Tag Series
RFID protocol
EPC Class 1 Gen 2, ISO 18000-6C
Frequency
(US) 902-928 MHz,(EU) 865-868 MHz
Chip
NXP UCODE 8
Memory
EPC 128bits, User 0bits, TID 96bits
Write endurance
100,000 cycles
Function
Read / write
Data retention
50 years
Applicable surface
metal surface
Read range
0 to 12.5 m - (US) 902-928 MHz, metal surface
Warranty
1 years
Dimensions
62.0x29.0 mm,(hole: diameter3.5 mm x 2)
Thickness
12 mm
Material
PEEK
Color
Black
Installation
screws (M3)
Weight
15.0 g
Ingress protection
IP65
Storage temperature
-60 C to + 260 C (300 Cwithstanding100 hours)
Operating temperature
-40 C to + 150 C
Certifications
REACH, RoHS, CE
