Technical Specifications
Product model
RGW2626
Product category
Industrial & High-Temperature RFID Tag Series
RFID protocol
EPC Class 1 Gen 2, ISO 18000-6C
Frequency
(US) 902-928 MHz,(EU) 865-868 MHz
Chip
NXP UCODE 8
Memory
EPC 128bits, User 0bits, TID 96bits
Write endurance
100,000 cycles
Function
Read / write
Data retention
50 years
Applicable surface
metal surface
Read range
0 to 6 m - (US) 902-928 MHz, metal surface
Warranty
1 years
Dimensions
26.0x26.0 mm,(hole: diameter4 mm x 2)
Thickness
5.5 mm
Material
PPS housing, PCB antenna
Color
Black
Installation
adhesive backing, screws,strapping
Weight
6.5 g
Ingress protection
IP68
Storage temperature
-40 C to + 100 C (high-temperature resistant 230 C for 30 minutes,180 C for 120 minutes)
Operating temperature
-40 C to + 100 C
Certifications
REACH, RoHS, CE
