HF RFID security detection with an independent controller and multi-channel operation.
ISO 15693 Detection
Three-dimensional HF tag reading with adjustable RF power and sensitivity.
Independent Controller
Controller can be integrated or externally mounted and supplies safe voltage to the gate panels.
Alarm and Traffic Records
Sound-and-light alarm, infrared people counting and persistent event records.
Automatic Channel Setup
Supports multi-channel linkage and automatic main and auxiliary role assignment.
RFID & Security
| Supported standard | ISO 15693 |
|---|
| RF power | 1-8 W, adjustable |
|---|
| Passage width | 80-140 cm; 90 cm recommended |
|---|
| Anti-theft modes | EAS, AFI, EAS+AFI, DSFID and AFI+DSFID |
|---|
| Alarm modes | Autonomous and command-controlled |
|---|
| Alarm records | At least 100,000 |
|---|
Interface, Display & Records
| Communication | Ethernet, RS232, USB and Wi-Fi |
|---|
| Network | TCP/IP; static IP or DHCP |
|---|
| Display | 8-digit traffic display |
|---|
| Alarm | Sound and light standard; voice optional |
|---|
| Linkage outputs | 4 relay outputs and 2 MOS outputs |
|---|
| Daily traffic records | At least 3,500 |
|---|
| Same-day entry/exit records | At least 40,000 |
|---|
Physical & Compliance
| Power input | AC 100-240 V, 50-60 Hz |
|---|
| Housing | Acrylic, aluminum profile and sheet metal |
|---|
| Dimensions | 1660 x 629 x 120 mm, tolerance ±2 mm |
|---|
| Base dimensions | 629 x 120 x 16 mm |
|---|
| Weight | Controller approx. 31 kg; main approx. 30.5 kg; auxiliary approx. 29 kg |
|---|
| Referenced standards | GB 4943.1-2011; EN 62233:2008 |
|---|
